Quick Fit Solderless L Shape Corner Connector For DC LED Strip Lights

A solderless L-shape connector designed for DC low voltage LED strips. It lets you join two strips at a 90° angle without soldering, making corners and turns quick and easy during installation.

How to Use:

1. Turn off the power – Always disconnect the power supply first.
2. Cut the LED strips – Cut only on the marked cut line.
3. Open the connector – Lift the small plastic clip.
4. Insert the first strip – Slide the strip into one side of the connector. Make sure the copper pads sit under the metal pins.
5. Insert the second strip – Insert the strip from the other side of the L-shape. Align all pins correctly: the copper pads must match the metal pins. For multi-channel strips (RGB, RGBW, etc.), ensure each channel lines up.
6. Close the clip firmly – Press down until it clicks shut.
7. Test the connection – Turn the power back on and check both strips light up correctly.

Notes:

1. Supplied as a pack of 5 connectors.
2. Double-check polarity (+ / –) before closing the connector to ensure correct operation.
3. For DC low voltage LED strips only. Not suitable for mains or high voltage strip lights.

Product	Length(mm)	Width(mm)	Height(mm)
SMD 8MM 2 PIN L shape	17	9.8	4.5
SMD 10MM 2 PIN L shape	17	11.7	4.5
SMD 10MM 3 PIN L shape	17	11.7	4.5
SMD 10MM 4 PIN L shape	17	11.7	4.5
SMD 12MM 4 PIN L shape	12.2	13.7	5
SMD 12MM 5 PIN L shape	21.5	15.2	7
SMD 12MM 6 PIN L shape	21.5	16.2	7



Product	Length(mm)	Width(mm)	Height(mm)
COB 5MM 2PIN L shape	13.3/16.7	6.7	4.55
COB 8MM 2PIN L shape	16.3/19.8	9.7	4.55
COB 10MM 2PIN L shape	18.4/21.7	11.7	4.55
COB 10MM 3PIN L shape	18.4/21.7	11.7	4.55
COB 10MM 4PIN L shape	18.4/21.7	11.7	4.55
COB 12MM 3PIN L shape	12	13.7	5
COB 12MM 5PIN L shape	12	13.7	5
COB 12MM 6PIN L shape	12	13.7	5
